ZE650 ZEPHIR LIGHT


EVA sheets, easily thermos-mouldable, ideal for orthopaedic applications.

Compound or Variant Thickness Colours Packaging Notices Note
L18 10.0
BK
 1FG

Hardness: ± 30 ShA
Density: ± 0,18 g/cm³
12.0
BK
 1FG
S20 2.0
WH
 1FG

Light and flexible sheets, with a great shock absorbing effect
Hardness: ± 40 ShA
Density: ± 0,20 g/cm³
4.0
WH
 1FG
5.0
BK
DB
BE
WH
 1FG
10.0
BK
DB
B1
BE
WH
 1FG
12.0
WH
 1FG
15.0
BK
B1
 1FG
20.0
BK
B1
 1FG
35.0
B1
 1FG
N30 3.0
BK
DB
BE
WH
 1FG

Standard sheets
Hardness: ± 55 ShA
Density: ± 0,30 g/cm³
4.0
BK
DB
 1FG
5.0
BK
DB
BE
WH
GR
 1FG
6.0
BK
DB
BE
WH
GR
 1FG
8.0
BK
 1FG
10.0
BK
DB
BE
WH
GR
 1FG
12.0
BK
GR
 1FG
15.0
BK
BE
WH
 1FG
20.0
BK
DB
BE
WH
GR
 1FG
D20 1.2
WH
BK
 1FG On demand, with M.O.Q.

Light and stiff sheets
Hardness: ± 60 ShA
Density: ± 0,25 g/cm³
2.0
BK
WH
 1FG Not sanded
3.0
BK
DB
 1FG
4.0
BK
WH
 1FG
5.0
BK
DB
WH
EB
B1
 1FG
6.0
BK
DB
B1
WH
EB
 1FG
8.0
BK
WH
EB
 1FG
10.0
BK
DB
B1
WH
EB
 1FG
12.0
BK
 1FG
15.0
BK
DB
B1
WH
 1FG
18.0
WH
 1FG
20.0
BK
DB
B1
WH
 1FG
23.0
DB
WH
 1FG
24.0
BK
 1FG
35.0
BK
 1FG
40.0
BK
 1FG
D35 35.0
BK
 1FG

Very stiff and hard sheets
Hardness: ± 75 ShA
Density: ± 0,35 g/cm³

Sheets ZE650L18 dimensions: 100 x 130 ± 3 cm
Sheets ZE650S20 dimensions: 90x120 ± 3 cm
Sheets ZE650N30 dimensions: 80x110 ± 3 cm
Sheets ZE650D20 dimensions: 90x120 ± 3 cm
Sheets ZE650D35 dimensions: 74 x 99 ± 3 cm

Other thicknesses are available with a m.o.q. of 10 sheets per thickness.

Gluing: For a perfect bonding we recommend the use of ADESVIG Tenax Plus neoprene glue (2 layers) or ADESVIG PVC glue, with a polyurethane base, after applying ERP primer; in both cases we recommend initial cleaning of the parts with ADESVIG CLEANER solvent.
